- Use with Desktop and Broadcast Applications
- Use with Servers, Workstations and Routers
- Audio Embedder
- SD SDI and AES Inputs
- Embedded SDI Output
BrightEye 21 is an embedder, or multiplexer, with one serial digital video input and two AES digital audio inputs. The two AES audio streams are embedded into the digital video stream. The output is a serial digital video stream that contains the original video plus the two AES pairs.
Audio mixing, level adjustments, and channel shuffling are accessed through BrightEye Mac or PC software. Audio group selection is also made through BrightEye Mac or PC software. Use BrightEye 21 in desktop and broadcast applications.
